Product Display

Product Parameters

Machine Name FDG-2000 Washing Powder Pressure Type Spray Dryer
Voltage/Frequency 380V/50Hz
Capacity 2000kg/h
Handling (Initial) Capacity 3920kg/h
Material SUS201& Carbon steel
Dryer Type Pressure type spray dryer tower
Size of Dryer Tower Body 5500mm*3mm*34100mm
Emission Requirements Emissions of China GB Standard (dustiness?50mg/m3 Standard
dry air)
Machine Configuration Drying System (dry tower body, skeleton, hot air distributor, observation manhole,
discharge pipe & cleaning manhole, cone pneumatic hammer, steel support,
hot air duct into the tower, connecting duct with variable diameter, thermal
insulation material, stirring pot with heating, electric heat, filter),
Heating System (gas fuel furnace), Air Supply System (fan, air filter),
Feeding Pump, Spray Gun, Receiving System (high efficiency cyclone separator,
discharge valve, stock bin), Exhaust System (pipes, cloth bag dust
collector), Induced Draft Fan, Control System (control cabinet, frequency
converter, temperature sensor, pressure sensor), Auxiliary System (handrail,
escalator, site wire and cable bridge steelworks, site steel platform)
Function It is multi-functional, capable of producing washing powder as well as applying
to food industry and medical industry etc. to produce puffed products
